USGS 04087240 ROOT RIVER AT RACINE, WI

PROVISIONAL DATA SUBJECT TO REVISION

Click to hidestation-specific text

LOCATION.--Lat 42°45'05", long 87°49'25", in NW1/4 NE 1/4 sec.6, T.3 N., R.23 E., Racine County, Hydrologic Unit 04040002, on left bank 30 ft downstream from State Highway 38 bridge in Racine, 350 ft downstream from Horlick Dam, and 5.2 mi upstream from mouth.

DRAINAGE AREA.--190 square miles, of which 1.24 square miles is probably noncontributing.

PERIOD OF RECORD.--August 1963 to present.

REVISED RECORD.--WDR WI-80-1: Drainage area.

GAGE.--Water-stage recorder. Datum of gage is 613.87 ft (NAVD88), from WDOT benchmark. Prior to Feb. 5, 1964, nonrecording gage on bridge 30 ft upstream.

REMARKS.--Gage-height telemeter at station.

OPERATED IN COOPERATION WITH:

City of Racine Logo City of Racine

Southeastern Wisconsin Regional Planning Commission Logo SEWRPC

Additional Information:

National Weather Service Logo National Weather Service Flood Forecast Page

Boating safety tips
This station managed by the USGS Wisconsin Water Science Center - Middleton WI.

Available Parameters Available Period

1986-10-01  2020-04-07
2017-10-01  2020-04-07







 (7)


  -- or --






Summary of all available data for this site
Instantaneous-data availability statement


Discharge, cubic feet per second

Most recent instantaneous value: 163 04-07-2020   10:00 CDT
Graph of

Add up to 2 more sites and replot for "Discharge, cubic feet per second"

?



Create presentation-quality / stand-alone graph.   Subscribe to WaterAlert


Daily discharge, cubic feet per second -- statistics for Apr 7 based on 56 water years of record more
Min
(2000)
25th
percen-
tile
Most Recent
Instantaneous
Value Apr 7
Median Mean 75th
percen-
tile
Max
(1988)
45.0 107 163 179 316 462 1260


Gage height, feet

Most recent instantaneous value: 3.08 04-07-2020   10:00 CDT
Graph of

Add up to 2 more sites and replot for "Gage height, feet"

?



Create presentation-quality / stand-alone graph.   Subscribe to WaterAlert
