[!] ICE EFFECTS ON STREAMFLOW -- During cold weather, stage and discharge values may be affected by ice at some streamgages. Streamgages experiencing ice conditions will have the discharge record temporarily disabled to prevent the display of erroneous discharge values. Display of discharge record will resume when it is determined that ice conditions are no longer present. Adjustment of data affected by ice can only be done after detailed analysis.



* IMPORTANT: Next Generation Station Page

USGS 01472157 French Creek near Phoenixville, PA

PROVISIONAL DATA SUBJECT TO REVISION

Click to hidestation-specific text




Station gage imageSTATION.--01472157 FRENCH CREEK NEAR PHOENIXVILLE, PA
LOCATION.--Lat 40`09'05", long 75`36'06", Chester County, Hydrologic Unit 02040203, on right bank 70 ft downstream from two-span county bridge on French Creek Road, 4.5 mi northwest of Phoenixville, and 7.3 mi upstream from mouth.
DRAINAGE AREA.--59.1 square miles.
PERIOD OF RECORD.--October 1968 to current year.
GAGE.--Water-stage recorder, water-quality monitor and crest-stage gage. Elevation of gage is 160 ft above National Geodetic Vertical Datum of 1929, from topographic map. Prior to Nov. 7, 1968, non-recording gage at site 70 ft upstream at same datum. Satellite telemetry at station.
COOPERATION.--Station established and maintained by the U.S. Geological Survey. Funding for the operation of this station is provided by Chester County Water Resources Authority and the U.S. Geological Survey.
GAGE HEIGHTS OF IMPORTANCE.-
Supplied by USGS: Maximum recordable gage height (stage sensor operational limit) - 16.3 ft; Data transmitter operational limit - 17.0 ft, at 8 ft - approx low point Hoffecker Road across from gage.
Supplied by NWS: No flood stage has been determined for this station.
This station managed by the PAWSC New Cumberland Office.

Available Parameters Available Period

2016-10-01  2020-01-28
1990-10-01  2020-01-28
2007-10-01  2020-01-28
2007-10-01  2020-01-28







 (7)


  -- or --






Summary of all available data for this site
Instantaneous-data availability statement


Temperature, water, degrees Celsius

Most recent instantaneous value: 4.4 01-28-2020   23:30 EST
Graph of  Temperature, water, degrees Celsius

Add up to 2 more sites and replot for "Temperature, water, degrees Celsius"

?



Create presentation-quality / stand-alone graph.   Subscribe to WaterAlert




Discharge, cubic feet per second

Most recent instantaneous value: 110 01-28-2020   23:30 EST
Graph of  Discharge, cubic feet per second

Add up to 2 more sites and replot for "Discharge, cubic feet per second"

?



Create presentation-quality / stand-alone graph.   Subscribe to WaterAlert


Daily discharge, cubic feet per second -- statistics for Jan 29 based on 51 water years of record more
Min
(1981)
25th
percen-
tile
Median Most Recent
Instantaneous
Value Jan 29
Mean 75th
percen-
tile
Max
(1994)
13.0 48 70 110 114 123 840


Gage height, feet

Most recent instantaneous value: 5.06 01-28-2020   23:30 EST
Graph of  Gage height, feet

Add up to 2 more sites and replot for "Gage height, feet"

?



Create presentation-quality / stand-alone graph.   Subscribe to WaterAlert




Turbidity, water, unfiltered, monochrome near infra-red LED light, 780-900 nm, detection angle 90 +-2.5 degrees, formazin nephelometric units (FNU)

Most recent instantaneous value: 5.0 01-28-2020   23:30 EST
Graph of  Turbidity, water, unfiltered, monochrome near infra-red LED light, 780-900 nm, detection angle 90 +-2.5 degrees, formazin nephelometric units (FNU)

Add up to 2 more sites and replot for "Turbidity, water, unfiltered, monochrome near infra-red LED light, 780-900 nm, detection angle 90 +-2.5 degrees, formazin nephelometric units (FNU)"

?



Create presentation-quality / stand-alone graph.   Subscribe to WaterAlert
