USGS 01467087 Frankford Creek at Castor Ave, Philadelphia, PA

PROVISIONAL DATA SUBJECT TO REVISION

Click to hidestation-specific text




Station gage imageSTATION.--01467087 FRANKFORD CREEK AT CASTOR AVENUE, PHILADELPHIA, PA
LOCATION.--Lat 40`00'57", long 75`05'50", Philadelphia County, Hydrologic Unit 02040202, on left bank at upstream side of Castor Avenue bridge, and 2.8 mi upstream from mouth in northeast Philadelphia.
DRAINAGE AREA.--30.4 square miles.
PERIOD OF RECORD.--July 1982 to current year.
GAGE.--Water-stage recorder, water-quality monitor and concrete control. Datum of gage is 16.56 ft above National Geodetic Vertical Datum of 1929. Satellite telemetry at station.
COOPERATION.--Station established and maintained by the U.S. Geological Survey. Funding for the operation of this station is provided by the City of Philadelphia, Water Department and the U.S. Geological Survey.
REMARKS.--Calibration of specific conductance, dissolved oxygen, and pH instrumentation is conducted exclusively by Philadelphia Water Department personnel with USGS oversight. Erroneous or missing data, resulting from instrument malfunction, are not the responsibility of USGS.
GAGE HEIGHTS OF IMPORTANCE.-
Supplied by NWS: Action stage-6 ft; Flood stage-7 ft; Moderate flood stage-8 ft; Major flood stage-10 ft.
This station managed by the PAWSC Downingtown Field Office.

Available Parameters Available Period

2018-10-01  2024-11-23
1990-10-19  2024-11-23
2021-11-23  2024-07-10
2021-11-23  2024-07-10
2021-11-23  2024-07-10
2021-11-23  2024-07-10
2021-11-23  2024-07-10
2007-10-01  2024-11-23
2021-11-23  2024-07-10
2018-10-01  2024-11-23
2024-07-25  2024-11-23
2024-07-25  2024-11-23
2024-07-25  2024-11-23
2021-11-23  2024-11-23
2021-11-23  2024-07-10
2021-11-23  2024-07-10
2024-07-25  2024-11-23







 (7)

  -- or --




Summary of all available data for this site
Instantaneous-data availability statement

Temperature, water, degrees Celsius
Most recent instantaneous value: 8.0 11-23-2024   02:45 EST
Graph of Temperature, water, degrees Celsius

Add up to 2 more sites and replot for "Temperature, water, degrees Celsius"

?

Note



Create presentation-quality / stand-alone graph.   Subscribe to
?
WaterAlert

See this graph on the Monitoring Location Pages

Share this graph |


Discharge, cubic feet per second
Most recent instantaneous value: 18.5 11-23-2024   02:45 EST
Graph of Discharge, cubic feet per second

Add up to 2 more sites and replot for "Discharge, cubic feet per second"

?

Note



Create presentation-quality / stand-alone graph.   Subscribe to
?
WaterAlert

See this graph on the Monitoring Location Pages

Share this graph |

Daily discharge, cubic feet per second -- statistics for Nov 23 based on 40 water years of record more
Min
(2002)		 25th
percen-
tile		 Median Most Recent
Instantaneous
Value Nov 23		 75th
percen-
tile		 Mean Max
(2012)
4.00 9.5 13 18.5 20 26 262

Discharge, cubic feet per second, EXPERIMENTAL DATA, [Ensemble (average) of methods]

-- Data temporarily unavailable for the time period specified --

Discharge, cubic feet per second, EXPERIMENTAL DATA, [PC Method-learned]

-- Data temporarily unavailable for the time period specified --

Discharge, cubic feet per second, EXPERIMENTAL DATA, [PC Method]

-- Data temporarily unavailable for the time period specified --

Discharge, cubic feet per second, EXPERIMENTAL DATA, [Surface Velocity Radar-learned]

-- Data temporarily unavailable for the time period specified --

Discharge, cubic feet per second, EXPERIMENTAL DATA, [Surface Velocity Radar]

-- Data temporarily unavailable for the time period specified --

Gage height, feet
Most recent instantaneous value: 1.67 11-23-2024   02:45 EST
Graph of Gage height, feet

Add up to 2 more sites and replot for "Gage height, feet"

?

Note



Create presentation-quality / stand-alone graph.   Subscribe to
?
WaterAlert

See this graph on the Monitoring Location Pages

Share this graph |


Gage height, feet, EXPERIMENTAL DATA, [NAVD88 RQ30]

-- Data temporarily unavailable for the time period specified --

Specific conductance, water, unfiltered, microsiemens per centimeter at 25 degrees Celsius
Most recent instantaneous value: 339 11-23-2024   02:45 EST
Graph of Specific conductance, water, unfiltered, microsiemens per centimeter at 25 degrees Celsius

Add up to 2 more sites and replot for "Specific conductance, water, unfiltered, microsiemens per centimeter at 25 degrees Celsius"

?

Note



Create presentation-quality / stand-alone graph.   Subscribe to
?
WaterAlert

See this graph on the Monitoring Location Pages

Share this graph |


Dissolved oxygen, water, unfiltered, milligrams per liter
Most recent instantaneous value: 8.9 11-23-2024   02:45 EST
Graph of Dissolved oxygen, water, unfiltered, milligrams per liter

Add up to 2 more sites and replot for "Dissolved oxygen, water, unfiltered, milligrams per liter"

?

Note



Create presentation-quality / stand-alone graph.   Subscribe to
?
WaterAlert

See this graph on the Monitoring Location Pages

Share this graph |


Dissolved oxygen, water, unfiltered, percent of saturation
Most recent instantaneous value: 75 11-23-2024   02:45 EST
Graph of Dissolved oxygen, water, unfiltered, percent of saturation

Add up to 2 more sites and replot for "Dissolved oxygen, water, unfiltered, percent of saturation"

?

Note



Create presentation-quality / stand-alone graph.   Subscribe to
?
WaterAlert

See this graph on the Monitoring Location Pages

Share this graph |


pH, water, unfiltered, field, standard units
Most recent instantaneous value: 7.4 11-23-2024   02:45 EST
Graph of pH, water, unfiltered, field, standard units

Add up to 2 more sites and replot for "pH, water, unfiltered, field, standard units"

?

Note



Create presentation-quality / stand-alone graph.   Subscribe to
?
WaterAlert

See this graph on the Monitoring Location Pages

Share this graph |


Barometric pressure (BP), uncorrected, pounds per square inch
Most recent instantaneous value: 14.4500 11-23-2024   02:45 EST
Graph of Barometric pressure (BP), uncorrected, pounds per square inch

Add up to 2 more sites and replot for "Barometric pressure (BP), uncorrected, pounds per square inch"

?

Note



Create presentation-quality / stand-alone graph.   Subscribe to
?
WaterAlert

See this graph on the Monitoring Location Pages

Share this graph |


Photosynthetically active radiation (average flux density on a horizontal surface during measurement interval), micromoles of photons per square meter per second
Most recent instantaneous value: -27.0 11-23-2024   02:45 EST
Graph of Photosynthetically active radiation (average flux density on a horizontal surface during measurement interval), micromoles of photons per square meter per second

Add up to 2 more sites and replot for "Photosynthetically active radiation (average flux density on a horizontal surface during measurement interval), micromoles of photons per square meter per second"

?

Note



Create presentation-quality / stand-alone graph.   Subscribe to
?
WaterAlert

See this graph on the Monitoring Location Pages

Share this graph |
